JACOBSEN TR330
JACOBSEN TR330
Comfort, cut quality, maneuverability, and power come together to make a mower that can safely reach every blade of grass on your golf course. The TR330 provides Jake’s Signature Cut Trusted by Generations and side-shifting reels can trim around bunkers, ponds, lakes, and other hazards with ease.
KEY ATTRIBUTES
REELS AND BLADES
TRACTION, BRAKES AND SPEED
WEIGHT AND DIMENSIONS
KEY ATTRIBUTES
| MOWER CUTTING WIDTH | 72″ (1.83 m) or 84″ (2.13 m) featuring ADAPTISHIFT™ with up to 12″ (30.5 cm) of offset |
|---|---|
| MOWER HEIGHT OF CUT | 0.37 – 2.75″ (9.5 – 69.8 mm) |
| BLADES PER REEL | 5, 7 or 11 |
| FUEL/BATTERY CAPACITY (+RUN TIME) | 7.6 gal. (28.7 L) |
| MOWER ENGINE | Kubota 24.8 HP (18.6 kW) Diesel |
| CUTTING CAPACITY | 4.5 – 5.3 acres (1.83 – 2.13 hectare) / hr |
| MOWER WARRANTY | 2 Years |
REELS AND BLADES
| NUMBER AND SIZE | 3 x 26″ (0.66 m) or 30″ (0.76 m) reels; 7″ (178 mm) diameter |
|---|---|
| BLADE MATERIAL | Hardened, high manganese carbon steel |
| CUTTING UNIT LIFT | Armrest mounted joystick |
| CUTTING FREQUENCY | – |
TRACTION, BRAKES AND SPEED
| TRACTION DRIVE | Parallel-series “on-demand” 3WD |
|---|---|
| REEL DRIVE | Fixed displacement hydraulic |
| HYDRAULIC SYSTEM | 8.7 gal. (33 L) capacity, full flow filtration (10 micron filter); GreensCare biodegradable oil |
| SERVICE BRAKES | Dynamic braking through hydrostatic drive |
| PARKING BRAKES | Service-free electronic wet disc |
| STEERING | Hydraulic power steering with tilt wheel |
| MOWING SPEED | 6.2 mph (10 kph) |
| TRANSPORT SPEED | 8.7 mph (14 kph) |
WEIGHT AND DIMENSIONS
| WEIGHT | 1664 – 2299 lbs. (755-1043kg) |
|---|---|
| LENGTH (LESS CATCHERS) | 97″ (2.46 m) |
| OVERALL HEIGHT INCLUDING ROPS | 80″ (2.04 m) |
| WHEEL BASE | 43.5″ (1.36 m) |
| TRANSPORT WIDTH | 83″ (2.11 m) |
| WORKING WIDTH | 83″ (2.11 m) |
