The F305 is a medium weight, four-wheel drive, 5 cutting unit fairway mower. It gives you reliable and unsurpassed productivity and revolutionized operator controls and a powerful yet clean Stage V 44HP Engine. The 26” (66cm) cutting units require no tools to adjust the reels and can easily be set to discharge grass to the front or rear.
| KEY ATTRIBUTES | |
|---|---|
| MOWER CUTTING WIDTH | 72″ (1.8 m) featuring ADAPTISHIFT™ with up to 12″ (0.3 m) of offset Cutting Width |
| MOWER HEIGHT OF CUT | 0.75 – 3.5″ (19 – 88 mm) |
| MOWER ENGINE | Kubota® 24.8 HP (18.6 kW) Diesel |
| CUTTING CAPACITY | 4.5 acres/hr at 6 mph (1.83 ha/hr at 10 kph) |
| TRANSPORT SPEED | 8.7 mph (14 kph) |
| FUEL/BATTERY CAPACITY (+RUN TIME) | 7.6 gal. (28.7 L) |
| MOWER WARRANTY | 2 Years |
| DECKS AND CUTTING UNITS | |
|---|---|
| NUMBER AND SIZE | 3 x 26″ (0.66 m) or 30″ (0.76 m) reels; 7″ (178 mm) diameter |
| NUMBER AND SIZE | 3 x 27″ (68.58 cm) TrueDeck rotary cutting units |
| BLADE MATERIAL | Hardened, carbon steel alloy |
| DECK LIFT/LOWER | Armrest mounted joystick |
| WEIGHT TRANSFER | Adjustable hydraulic, electronically activated operator control |
| DECK CONSTRUCTION | 9-gauge, stamped modular deck construction |
| TRACTION, BRAKES AND SPEED | |
|---|---|
| TRACTION DRIVE | Parallel-series “on demand” 3WD |
| DECK DRIVE | Fixed displacement hydraulic |
| HYDRAULIC SYSTEM | 8.7 gal. (33 L) capacity, full flow filtration (10 micron filter); GreensCare biodegradable oil. |
| SERVICE BRAKES | Dynamic braking through hydrostatic drive |
| PARKING BRAKES | Service-free electronic wet disc |
| STEERING | Hydraulic power steering with tilt wheel |
| MOWING SPEED | 6.2 mph (10 kph) |
| REVERSE SPEED | 3.7 mph (6 kph) |
| REVERSE SPEED | 3.7 mph (6 kph) |
| WEIGHT AND DIMENSIONS | |
|---|---|
| WEIGHT | 2004 lbs. (909 kg) |
| LENGTH | 122″ (3.10 m) |
| HEIGHT (ROPS UP) | 82″ (2.06 m) |
| WHEEL BASE | 61″ (1.54 m) |
| TRANSPORT WIDTH | 77″ (1.96 m) |
| WORKING WIDTH | 77″ (1.95 m) |
| FLUID CAPACITIES | Hydraulic System and Capacity: 8.7 gal., full flow filtration (10 micron filter); GreensCare biodegradable oil |
